Sarad
Smart Radon Sensor - CO2
Smart Radon Sensor - CO2 - the smart solution for building automatization systems
-Wide measurement range: 1 - 1,000,000 Bq
-High sensitivity - 3,3 cpm/1kBq
-Accuracy
Resistant to:
-temperature and humidity variations
-external radiation
-vibrations and any mechanical shocks
-Light LED (red, yellow, green) indication
-coal dioxide (CO2), humidity, and temperature measurement
-High-quality housing
-Battery and mains operation
-USB interface
-Time-resolved measurement
-Very large data storage
-Can be used in workplaces and in living rooms as a part of building automation systems
-Various interfaces for system integration (RS-485 ModBus RTU, analog output, switch output, and wireless interface)
-Professional Software Radon Vision
-DAkkS-accredited calibration according to the DIN EN ISO/IEC 17025:2018 included!
-Optional: direct controlling of ventilation equipment
SARAD’s outstanding detector technology defines a new level of Radon monitoring in buildings and workplaces, as requested by the recently introduced EU radiation protection regulations.
The Smart Radon Sensor offers very high sensitivity in a very small and shapely housing. Due to the detector technology, the instrument will not be affected by any variations in temperature and humidity, external radiation, mechanical shocks, and vibrations. The measurement starts as soon as the power is connected.
Various interfaces for system integration are available. The RS485 network interface can be operated either with the MODBUS RTU (industrial standard) or the proprietary SARAD protocol. The analogous output makes it easy to connect the Smart Radon Sensor to existing PLC’s. A stand-alone ventilation control system can be easily realized by the alert switch output. If no data line is available, the optionally integrated ZigBee wireless interface can be used for connection to a host system. The wide range of power input accepts all in building automation commonly used voltage supplies. For easy installation, all connections are available through a screw terminal.
Two AAA batteries are integrated to continue the measurement in case of power interruptions. All measurement results will be stored locally in non-volatile circular memory.
Sensors for coal dioxide (CO2), temperature, and humidity are integrated into the current version as a standard. There are options for barometric pressure measurement or without both CO2 and pressure sensors available.
The Smart Radon Sensor comes with the DAkkS-accredited calibration certificate according to the DIN EN ISO/IEC 17025:2018 and the latest release of the Radon Vision software.
A standard calibration is performed at a radon concentration of 3 000 Bq/m³, with the prior determination of the background effect. A second calibration point at a radon concentration of 300 Bq/m³ is possible on demand and at additional cost. A separate calibration certificate is created for each calibration point.
We use only high-quality and instrument-grade components for this product, which is manufactured in our company’s location in Dresden/Germany.
